Cooper&Hunter CHML-ID12RK2 (I)

The Cooper&Hunter CHML-ID12RK2 (I) is a compact concealed duct indoor unit from the Nordic Multi Light GEN VI range, designed for multi-split air conditioning systems. Delivering 3.50 kW cooling and 4.50 kW heating capacity, it provides efficient and discreet climate control for residential and commercial spaces.

Its compact 200 mm high design makes it ideal for concealed ceiling installation where available space is limited. The unit features increased external static pressure, multiple airflow settings and environmentally friendly R32 refrigerant, making it suitable for homes, offices, hotels, cafés, shops and other commercial premises.

Key Features

Compact 200 mm profile – ideal where ceiling installation space is limited.
3.50 kW cooling / 4.50 kW heating – year-round climate control.
High External Static Pressure – designed for efficient ducted air distribution.
7 Airflow Settings – airflow from 380 to 650 m³/h.
Quiet Operation – sound levels down to 32 dB(A).
R32 Refrigerant – modern refrigerant used by the Nordic Multi Light GEN VI system.
Centrifugal Fan – optimised for concealed duct applications.
Multi-Split Compatibility – designed as an indoor unit for compatible Cooper&Hunter multi-split systems.
Wi-Fi Availability – the GEN VI duct range supports Wi-Fi accessibility.
Optional Wired Controllers – different wired controller options are available as accessories.

Specification	Details
Model	CHML-ID12RK2 (I)
Series	Nordic Multi Light GEN VI Duct R32
Unit Type	Concealed Duct Indoor Unit
Cooling Capacity	3.50 kW
Heating Capacity	4.50 kW
Dehumidification	1.40 L/h
Fan Type	Centrifugal
Refrigerant	R32
Airflow Rate	650 / 560 / 520 / 480 / 450 / 410 / 380 m³/h
Power Supply	220–240 V / 50 Hz / 1 Phase
Indoor Unit Dimensions (L × D × H)	710 × 450 × 200 mm
Package Dimensions	1005 × 565 × 260 mm
Net / Gross Weight	19 / 23 kg
Sound Level	39 / 37 / 36 / 35 / 34 / 33 / 32 dB(A)
Liquid Pipe Connection	1/4″
Gas Pipe Connection	3/8″
Installation Type	Concealed Ceiling / Ducted
